Raised foam embroidery

3D Puff Embroidery Digitizing

3D puff digitizing builds a file that stitches over a layer of craft foam so the design stands up from the cap. The file needs higher density to hide the foam and tight edge closure so the waste tears away cleanly. We build for 2mm or 3mm foam at a flat price per design, and tell you which elements should stay flat.

Density set for the foam thickness
Edge closure for a clean tear-away
Advice on what to raise and what to keep flat
Upload your puff design → See all prices
Digitizing since 2015
Send the logo you want raised
Foam-ready files for caps and flat garments
From $15 per design
Built for 2mm or 3mm foam, stated with the file
Coverage dense enough that no foam shows
Edges closed tightly so waste foam tears away

Free quote, nothing to pay now. Need rush, formats or notes? Use the full form

All
Machine formats included
2mm
Foam for most lettering
3mm
Foam for large, simple shapes
Flat satin
For outlines on a puff design
4–8h
Standard delivery
At a glance

3D puff digitizing specs

What it isAn embroidery file built to stitch over craft foam, with density and edge closure planned for the foam rather than a flat file stitched thicker
Where it runsStructured caps and snapbacks most often; hoodies, jackets and other flat garments with stable backing
Foam thickness2mm for most lettering and medium shapes; 3mm for large, simple shapes that need a bolder lift
What raises wellBold block letters and simple icons. Script, serifs and small text stay flat; outlines are stitched as flat satin
On capsSequenced from the center outward for the cap frame: see how cap files are sized and sequenced
Files deliveredDST, PES, EXP, JEF, VP3 or your machine's format, plus a stitch simulation preview
What to sendArtwork, garment, finished size, the foam you stock (if any) and thread colors
PriceFlat rate per design; rush +50%. See the price table below
TurnaroundStandard 4–8 hours · Rush 2–4 hours · Super rush 1–2 hours, 24/7
How puff works

Puff is foam management, not thicker stitching

3D puff works by laying foam on the garment, stitching over it, and letting the needle perforate everything outside the design so the excess tears away. The thread has to cover the foam completely and cut it cleanly at every edge.

If the density is wrong, foam shows through and the piece is scrap. If the edge closure is loose, ragged foam stays attached around the outline and someone ends up picking it off by hand.

Puff is a popular cap upgrade for team and club caps and promotional headwear, but it does not suit every element. Fine lettering, thin serifs and small detail collapse under foam, so part of the job is deciding what gets raised and what stays flat.

A digitizer who puffs everything is not doing you a favor. We tell you when an element is too fine to hold foam and usually suggest a mixed design: bold shapes raised, detail stitched flat.

What we build in
01
Coverage for the foam
Density is raised specifically so no foam is visible through the thread, and matched to 2mm or 3mm foam. Under-covered puff cannot be rescued on the machine.
02
Edge closure
Every boundary gets closing stitches tight enough to perforate the foam, so the waste lifts away without ragged fragments left along the outline.
03
Puff-or-flat planning
Each element is judged for foam. Thin strokes, script and small text are built flat so they keep their shape next to the raised parts.
Suitability

Which parts of a logo should puff?

Foam needs wide, simple shapes to sit under. This is how we decide element by element.

Design elementPuff it?Why
Bold block lettersYesWide strokes hold the foam and give the satin stitches room to cover it fully
Simple icons and solid shapesYesClean, open outlines give the edge closure a firm line to cut the foam along
Script letteringKeep flatThin joining strokes are too narrow to hold foam and lose their shape
Serif typefacesKeep flatSerifs and hairline strokes collapse under the foam
Small text and fine detailKeep flatFoam swallows small letterforms; see building small text that stays readable
Outlines and bordersFlat satinA flat satin outline around raised shapes adds definition without foam underneath

Not sure where your logo falls? Tell us the garment when you order and we will advise which parts to raise.

Foam

Choosing 2mm or 3mm foam

2mm foam suits most lettering and medium-sized shapes. It gives a clear raised effect and needs less stitch coverage, so it is the safer choice for most cap logos.

3mm foam gives a bolder lift on large, simple shapes but needs more coverage to hide it. We state which thickness each file is built for. Running thicker foam than the file was planned for is a common cause of foam showing at the edges.

Pricing

What 3D puff digitizing costs

One flat price per puff design, whether it runs on a cap or a flat garment.

DesignPriceNotes
3D puff file$15Built for 2mm or 3mm foam, with raised and flat elements planned
Flat cap file (no foam)$12If the design is better stitched flat: see cap files
Rush (2–4 hours)+50%Added to the base price of the design
Super rush (1–2 hours)+50%Added to the base price of the design

Flat rate per design, not per 1,000 stitches. Every price includes all machine formats, a stitch simulation preview and unlimited revisions with no time limit. Standard delivery is 4–8 hours, 24/7.

Get a price for this design → See the full price list
Common problems

Bad puff vs properly built puff

Puff problems are almost always visible on the very first piece.

What goes wrong
Foam showing through the thread. Density set as if it were flat embroidery.
Ragged foam around the edges. Closure too loose to perforate, so waste stays attached.
Collapsed lettering. Thin strokes puffed when they should have stayed flat.
Thread breaks from over-density. Coverage overcorrected until the needle fights a wall of stitches.
Design walks on the cap. Puff file built without cap sequencing.
How we build it
Full coverage. Density calculated for the foam thickness, so nothing shows through.
Clean tear-away. Edge closure perforates the foam so the waste lifts off.
Raised and flat where each belongs. Bold shapes puffed, fine detail kept legible.
Balanced density. Enough coverage without overloading the needle.
Center-out on caps. Cap puff files are sequenced for the frame.
What to send

What we need for a puff file

  • Artwork in any format: vector is best, but a JPG, PNG or photo works
  • Garment: cap style, or the flat garment (hoodie, jacket, sweatshirt)
  • Finished size in inches, or the cap frame you run
  • Foam thickness you stock (2mm or 3mm), or ask us to recommend one
  • Which parts you want raised, if you already have a preference
  • Thread colors and your machine format (DST, PES, EXP…)
Upload your puff design →
How it works

From flat logo to raised design

Send the logo and garment
Tell us cap or flat garment and the foam you use, if you have a preference.
We plan foam and flat areas
Each element is marked raised or flat, then density and edge closure are built for the foam thickness.
Review the stitch preview
Check the simulation and ask for changes as often as you need.
Lay the foam and run
Stitch over the foam, then tear away the waste around the raised shapes.
FAQs

3D puff questions

2mm foam suits most lettering and medium-sized shapes. 3mm foam gives a bolder raised effect on large, simple shapes but needs more stitch coverage. We state which thickness the file is built for, so run the foam the file was planned around.
No. Bold block letters and simple icons raise well, but script, serifs, small text and fine detail collapse under foam, and outlines work best as flat satin. We tell you which elements should stay flat, and often suggest a design that mixes both.
Yes. Puff works on flat garments as well as caps, but soft or stretchy fabric needs stable backing under the foam. The file is built without cap sequencing, so tell us the garment when you order.
The edge stitching was not tight enough to perforate the foam, so the waste stayed attached. A heat gun can hide small fragments but does not fix the cause; the file needs rebuilding with proper edge closure.
Almost always the stitch density is too low for the foam thickness, or thicker foam was used than the file was built for. Puff needs noticeably more coverage than flat embroidery, and it cannot be corrected on the machine; the file has to be rebuilt.
Yes, and it is often the best result. Bold shapes are raised over the foam, while outlines, small text and fine detail stitch flat so they stay crisp. Tell us how you run puff jobs and we plan the file around it.
No, we supply the digitized file. Puff foam is sold by embroidery supply distributors in 2mm and 3mm thicknesses, and we tell you which one each file is built for.
A 3D puff file has one flat price per design, on a cap or a flat garment, including every machine format, a stitch simulation preview and unlimited revisions; see the price table on this page or the full price list. Rush (2–4 hours) and super rush (1–2 hours) add 50%.
Related puff and cap pages

Send the logo you want raised

Tell us the garment and the foam you run, and we'll build a puff file with the raised and flat parts planned, at a flat price per design.

Density and edges built for 2mm or 3mm foam
Every machine format included
Unlimited revisions, no time limit
